ABB ACS550-U1-023A-4+K467 - Variable Frequency Drive(VFD) 480V 15HP 23A IP21

ABB Drives
ABB ACS550-U1-023A-4+K467 - Variable Frequency Drive(VFD) 480V 15HP 23A IP21
Item Discontinued

GENERAL PURPOSE DRIVE , 15 HP, 23 A, 480 VAC , Voltage Range: 380-480V, NEMA 1 / UL Type 1 (IP21), Wall-mounted, Advanced Control Panel, PROFINET IO Adapter, 3-Phase Input, 3-Phase Output, Frame: R2

Item ID

ABB 3AUA0000033542

Manufacturer Part #

3AUA0000033542

AHC Part #

41485 Discontinued

Unit Size

1

Brand

ABB Drives

Features

  • Integral EMC filter as standard
  • Sensorless vector control
  • FlashDrop programming (unpowered drive)
  • Smaller physical size of internal option slots
  • Only Class T fuses required for high speed short circuit protection
  • Removable operator panel
  • Optional plug-in fieldbus modules
  • New conduit box is suitable for US and Europe
  • Easy connection of cables
  • Field upgradeable firmware
  • Two soft-keys that change according to the operator panel state
  • Many assistants including Start-up, Drive Optimizer, Real-time Clock, Diagnostics, Maintenance, Serial and PID
  • Advanced control panel permitting intuitive operation

Tech Specifications

TypeGeneral Purpose Drive
Power Rating15.4 HP
Output Voltage0-480 VAC
Input Voltage480 VAC
Number of Phases3-Phase Supply / 3-Phase Output
Current Rating15 A
Standard480V products: UL, cUL, CSA, CE, C-TICK, and GOST-R approvals. Low Voltage Directive 73/23/EEC with supplements. Machinery Directive 98/37/EC. EMC Directive 89/336/EEC with supplements. Quality assurance system ISO 9001 and Environmental system ISO 14001
ControlScalar (V/Hz), Vector: Speed, Vector: Torque
DisplayAdvanced Control Panel
EnclosureNEMA 1/UL Type 1 (IP21)
Environmental ConditionsTEMPERATURE: 15 to 40 degC (5 to 104 degF), 40 to 50 degC (104 to 122 degF) with derate. No frost allowed. / COOLING: Forced Air / ALTITUDE: Rated current available at 0 to 1000 m (3300 ft) reduced by 1% per 100 m over 1000 m (3300 ft) to 2000 m (6600 ft). / RELATIVE HUMIDITY: Lower than 95% (without condensation). / VIBRATION: Seismic Certified.
MountingWall-mounted
Size18.5 x 4.9 x 8.7 IN
OptionsPROFINET IOAdapter
Input Phase3-Phase Input
Output Phase3-Phase Output
Frame SizeR2
